Marsden OCS-Z Crane Scale


The Marsden OCS-Z is an easy to use, high capacity digital crane scale for heavy duty suspension weighing. It can be ordered with a capacity of 10 or 20 tonnes, making it the highest -capacity crane scale available from Marsden.


*
Total Price £845.00 ex VAT
In Stock: Delivery within 2 working days.

What is the OCS-Z?

It boasts infra-red remote control operation and is powered by rechargeable battery providing over 120 hours of continuous use.

Capacity:
10,000kg to 20,000kg

Graduations:
5kg to 10kg

Power Supply:
Internal rechargeable battery

Battery Life:
120 hours of continuous use

Weight of Scale:
70kg

Additional Features

  • Covered by 1 year warranty
  • Steel casing
  • Large bright red LED display
  • Stainless steel shackle and alloy steel hook
  • Infra-red remote control
  • Zero
  • Tare
  • Hold
  • Overload alarm
  • Auto-power off

Downloads

User Manuals Industrial Scales

Product Brochures Industrial Scales

General Information Certificates and General Information

How do crane scales work?

Crane scales provide you with high capacity weighing without the need for taking up floor space with a platform scale. Awkwardly shaped items can be weighed, space can be saved and very large items can be weighed as they are loaded onto a ship, lorry or train.

A crane scale is very easy to use. The hook on the top of the scale is simply attached to your crane, and the item to be weighed is attached to the hook on the base of the crane scale.

The scale measures the amount of downward pressure from the item that is hanging from the scale. The scale will convert this force into a reading that is then displayed on the digital readout. The OCS-Z has a large, bright red LED display for seeing readings from distances, and is operated by remote control.

Why should I choose the OCS-Z?

Choose the OCS-Z for heavy duty industrial weighing up to 20 tonnes.

The scale has a large bright red LED clearly visible from long distances and benefits from a long life internal 6V/ah rechargeable battery (over 120 hours’ continuous use). It has a stainless steel shackle and alloy steel hook. An overload alarm helps prevent damaging the scale, and remote control means easy operation at a safe distance from the scale.

Hold, Tare and Zero features come as standard and there is an easy to use digital calibration routine to ensure weighing accuracy.
